General Description
Solid wire/rod for welding of general constructions in mild steel
Smooth bead appearance
Stable arc and excellent feedability (Revix®70S-6)
Shielding gases (acc. EN 439)
|
GTAW |
l1 |
Inert gas Ar 100% |
|
GMAW |
М21 |
Mixed gas Ar+ >5-25% CO2 |
|
|
C1 |
Active gas 100% СО2 |
Approvals
|
|
ABS |
BV |
DNV |
GL |
LR |
RINA |
TÜV |
RMRS |
|
GTAW |
|
|
|
|
|
|
+ |
|
|
GMAW |
3SA, 3YSA |
SA3YM |
IIIYMS |
3YS |
3S, 3YS |
3YS |
+ |
3S, 3YS |
Packaging, available sizes and identification
|
|
|
Sizes, mm |
||
|
Process |
Unit: |
1.6 |
2.4 |
3.2 |
|
GTAW |
2 and 5 kg tube |
х |
х |
х |
Materials to be welded
|
Steel |
Code |
|
General structural steel |
EN 10025 |
|
Ship plates |
ASTM A131 |
|
Cast steel |
EN10213-2 |
|
Pipe material |
EN 10208-1/ EN 10208-2 |
|
|
API 5LX |
|
|
EN 10216-1/ EN 10217-1 |
|
Boiler & pressure vessel steel |
EN 10028-2 |
|
Fine grained steel |
EN 10113-2 / EN 10113-3 |
Mechanical properties, all weld metal
|
|
Process |
Shielding gas |
Condition |
Yield Strength (N/mm2) |
Tensile Strength (N/mm2) |
Elongation (%) |
Impact (ISO), J |
|||
|
-20оС |
-30оС |
-40оС |
-50оС |
|||||||
|
Typical values after welding |
GTAW |
I1 |
AW |
460 |
580 |
26 |
170 |
170 |
|
120 |
|
GMAW |
M21 |
AW |
520 |
600 |
25 |
110 |
|
70 |
|
|
Chemical composition (w%), typical, all weld metal
|
C |
Mn |
Si |
|
0.08 |
1.45 |
0.85 |
Classification
|
AWS A5.18/A5.18M |
:ER70S-6 |
|
EN 1668 |
:W 42 5 W3Si1 |
|
EN 440 |
:G 46 4 M G3Si1 |
