General Description
Solid wire for welding of aluminium-silicium alloys
Excellent feedability and very consistent welding performance.
Tight and stable arc.
Also available in 120 kg WUTPACK®Mini, that increases productivity by reducing time to change spools.
Shielding gas (acc. EN)
|
GTAW |
I1 |
Inert gas Ar 100% |
|
GMAW |
I1 |
Inert gas Ar 100% |
|
|
I3 |
Inert gas Ar + > 0-95% Не |
Approvals
|
|
TÜV |
|
GTAW |
+ |
|
GMAW |
+ |
Physical properties
|
Melting range |
573-625оС |
|
Density |
approximately 2680 kg/m3 |
Classification
|
AWS A5.10 |
:ER4043 |
|
ISO 18273 |
:S Al 4043 (AlSi5) |
Packaging, available sizes and identification
|
|
|
Sizes, mm |
|||||||
|
Process |
Unit: |
0.8 |
1.0 |
1.2 |
1.6 |
2.0 |
2.4 |
3.2 |
4.0 |
|
GTAW |
2.5 and 5 kg tube |
|
|
|
X |
X |
X |
X |
X |
|
GMAW |
0.5 kg plastic spool S100 |
X |
X |
X |
X |
|
|
|
|
|
|
7.6 kg plastic spool S300 |
X |
X |
X |
X |
|
|
|
|
|
|
7.0 kg basket spool BS300 |
X |
X |
X |
X |
|
|
|
|
|
|
120 kg WUTPACK®Mini |
|
|
X |
|
|
|
|
|
Chemical composition (w%), typical, all weld metal
|
Al |
Mn |
Si |
Ti |
Fe |
Zn |
Cu |
Mg |
|
rest |
0.01 |
4.7 |
0.001 |
0.3 |
0.002 |
0.01 |
0.004 |
Mechanical properties, all weld metal
|
|
Process |
Shielding gas |
Condition |
0.2% Yield Strength (N/mm2) |
Tensile Strength (N/mm2) |
Elongation (%) |
Impact (ISO), J |
|
|
+20оС |
-60оС |
|||||||
|
Typical values after welding |
GTAW |
I1 |
AW |
100 |
160 |
15 |
20 |
20 |
|
GMAW |
I1 |
AW |
100 |
160 |
15 |
20 |
20 |
|
