General description
High current capacity
Active flux for limited pass welding
High restraint cracking resistant
Suitable for rusty/dirty plates (at high current)
Applicable for low quality steels
Note: Use another flux for thin plates and multi-pass welding of thick plates (without particular caution)
Approvals
|
Wire grade |
ABS |
BV |
CRS |
Cont |
DNV |
PRS |
GL |
LRS |
RINA |
RMRS |
|
S-Revix®M12K |
|
|
3YM/2YT |
X |
2YT |
3YM/2YT |
3YM/2YT |
3YM/2YT |
3YM/2YT |
2YT |
|
S-Revis®A2 |
|
A3YM |
|
X |
2Y40M/3Y40T |
3YM/3YT |
3YM/3YT |
|
3YM/3YT |
2YM/3YT |
Chemical composition (w%) typical, all weld metal
|
Wire |
C |
Si |
Mn |
P |
S |
Mo |
|
S-Revix®L12 |
0.05 |
0.7 |
1.5 |
˂0.03 |
˂0.025 |
|
|
S-Revix®M12K |
0.08 |
0.9 |
1.7 |
˂0.03 |
˂0.025 |
|
|
S-Revis®A2 |
0.06 |
0.8 |
1.7 |
˂0.03 |
˂0.025 |
0.4 |
Classification
|
FLUX N 201 |
EN 760: S A CS/MS 1 88 AC H5 |
||
|
Flux/wire |
|
||
|
|
AWS A5.17/A5.23 |
EN 756:MR |
EN 756:TR |
|
Flux N 201 / S-Revix®L12 |
F7A2-EL12 |
S 38 2 CS/MS S1 |
|
|
Flux N 201 / S-Revix®M12K |
F7A2-EM12K |
S 42 2 CS/MS S2Si |
S 4T 0 CS/MS S2Si |
|
Flux N 201 / S-Revis®A2 |
F9A0-EA2-G |
S 50 0 CS/MS S2Mo |
S 4T 2 CS/MS S2Mo |
Suggestions for use
|
Wire |
Characteristics |
Applications |
|
S-Revix®L12 |
Lowest cost combination |
Flat fillet,large throat |
|
S-Revix®M12K |
Reliable properties |
Butt joints in two passes,in medium and thick plates |
|
S-Revis®A2 |
For good impact toughness as welded TR could be selected |
Flux backing,modified series arc-welding Low quality steels |
Flux characteristics
|
Current type (А) |
DC (+/-)/AC |
|
Basicity |
0,8 |
|
Solidification speed |
Low, high yield slag |
|
Density (kg/dm2) |
1,2 |
|
Grain |
1-16 |
Packaging, available sizes and indentification
|
Unit type |
Netto weight (kg) |
|
Bag |
25 |
|
«WUTPACK®-SuperBag» |
25 |
|
Steel drum |
250 |
|
Big Bag |
1000 |
Mechanical properties, all weld metal
|
Wire |
Condition |
Yield Strength 0,2 % (N/mm2) |
Tensile Strength (N/mm2) |
Elongation (%) |
Impact (ISO), J |
|
|
0оС |
+20оС |
|||||
|
S-Revix®L12 |
MR |
380 |
500 |
28 |
80 |
50 |
|
S-Revix®M12K |
MR |
440 |
530 |
28 |
100 |
50 |
|
|
TR |
˃420 |
˃540 |
|
65 |
|
|
S-Revis®A2 |
MR |
480 |
600 |
|
80 |
40 |
|
|
TR |
˃440 |
˃540 |
|
100 |
55 |
