Elex® RC 6012
General description
All position rutile electrode with excellent vertical down welding properties
Shipbuilding repairs
Excellent on painted or rust-covered steel
Recommended for bridging wide gaps
Weldable in all positions with one current setting
Current type
AC/DC electr.-
Application advice
Weldable in all positions with one current setting
vendor code: 785789
Classification
|
AWS A5.1 |
:E6012 |
|
ISO 2560-A |
:E 38 0 RC 11 |
Welding positions
Materials to be welded
|
Steel |
Code |
Type |
|
General structural steel |
EN 10025 |
S185,S235,S275 |
|
Ship plates |
ASTM A 131 |
Grade A, B, D |
|
Fine grained steel |
EN 10113-2 EN 10113-3 |
S275 |
Chemical composition (w%), typical, all weld metal
|
С |
Mn |
Si |
|
0.12 |
0.5 |
0.6 |
Mechanical properties, all weld metal
|
|
Condition |
Yield strength, (N/mm2) |
Tensile strength (N/mm2) |
Elongation (%) |
Impact (ISO), J |
|
|
оС |
||||||
|
Required |
AWS A5.1 |
|
min.331 |
min.414 |
min.17 |
not required |
|
ISO 2560-A |
|
min.380 |
470-600 |
min.20 |
min.47 |
|
|
Typical values after welding |
AW |
470 |
550 |
23 |
56 |
|
