Eleal® 3003
General description
Aluminum electrode.
Especially for welding forged and cast aluminum-magnesium alloys and aluminum-manganese alloys.
Good weldability, no porosity.
Current type
DC electr. +
Application advice
If the thickness is more than 10 mm,it is advisable to preheat at 150 - 250оС
Classification
|
AWS A5.3 |
:E3003* |
|
ISO 18273 |
:Al 3103 (AlMn1) |
Welding positions
Materials to be welded
|
Type |
W.Nr. |
|
AlMn1 |
3.0515 |
|
AlMn1Mg1 |
3.0526 |
|
AlMg1 |
3.3315 |
Chemical composition (w%), typical, all weld metal
|
Al |
Mg |
Fe |
Cu |
Mn |
Zn |
Others |
|
rest |
0.15 max |
0.6 max |
0.02 max |
0.9-1.2 |
0.09 max |
0.15 max |
Mechanical properties, all weld metal
|
|
Condition |
0.2% Yield Strength |
Tensile Strength (N/mm2) |
Elongation (%) |
|
Typical values after welding |
AW |
40 |
110 |
20 |
